Product detailsThe KVM-DV04 allow up to four IBM compatible computers to be controlled from one keyboard, one mouse and one DVI monitor. Switching between computers is as easy as pressing the button on the front of the switch or by entering a hot-key command from your keyboard, no interface card or software is required, the switch is independent of operating systems, and allows the attached computers to run different applications. Specification - Cascade configuration expands system capability
- Auto scan automatically selects computers sequentially
- Supports Microsoft IntelliMouse (Pro), IntelliTrackball
- Hot-key functions allow easy computer access
- Built-in buzzer for hot-key command confirmation
- Keyboard states automatically saved and restored when switching computers
- Operating system independent, transparent to all applications
- True plug and play system configuration
- Keyboard and mouse can be hot plugged at any time
- DVI-I interface
- DDC2B compatible
- Power-free operation
- Computer Port : 4
- Cascade control : Up to 16
- Front Panel button control : 4
- Hot plug and play : Yes
- Hot-key control : Yes
- Automatic scan interval : 3, 8, 15, 30 seconds
- Cable Length (Max) : 30 Mtr at Console, 30 Mtr at PC
- Monitor Type : DVI-I
- Computer keyboard connector : PS/2
- Mouse : PS/2
- Monitor : DVI-I Female
- H x W x D (mm) : 44 x 220 x 130
- Weight : 420g 900g
- Power Supply Optional : 9v DC, 500 mA
 |
